TBS2660 Professional H.265 IP Video decoder
- Product Model: TBS2660
- Weight: 1,500.00g
- Price in reward points: 25000
Out Of Stock
US$499.00
Introduction
TBS2660 is a Professional H.265 IP Video decoder with HDMI/VGA, composite, and analog audio outputs, which decodes digital video and audio streams into analog video signals, this allows analog devices such as monitors and video switches to be connected to an IP-based video system. Built-in with high-performance A17 processor, TBS2660 is a codec engine with the ability to decode up to 16 channels 1080p video, compatible with multi- protocol , support RTP/RTSP/HTTP input (TS, NON TS) h264/h265.
TBS2660 can be paired with the TBS2603 / TBS2630 H.265 HDMI Encoder (sold separately), allowing up to Full HD point-to-point video links over the Internet.
Applications:
- IPTV
- HD Video Surveillance
- Video Conference
- Teaching/Campus
Broadcast - Hotel TV system
- Live Broadcast
works?
TBS2660 H.265 IP Video decoder + TBS2603 HD H.264/H.265 HDMI Video Encoder
TBS2660 H.265 IP Video decoder + TBS2630 16 channel HD H.264/H.265 HDMI Video Encoder
TBS2660 H.265 IP Video decoder + MIO Pro AMD Professional IPTV Streaming Server
| Standard | |
| Video Decoding Standard | H.265 Main Profile Level5.1 |
| H.264 Baseline/Main/High Profile level5.0 | |
| MPEG4 SP L0~L3/ASP L0~L5 | |
| MJPEG/JPEG Baseline | |
| Video Encoding Standard | H.264 Baseline/Main/High Profile Level5.1 |
| MJPEG/JPEG Baseline | |
| Supported protocols | RTP/RTSP/HTTP/Sat2IP |
| Decode | 4x4K*2K(3840*2160)@30fps/2x4Kx2K(3840*2160)@60fps H.265/H.264 |
| 16x1080p@30fps /8x1080p@60fpsH.265/H.264 | |
| 32x720p@30fps/16x720p@60fps H.265/H.264 | |
| Hardware | |
| Network interface: | 2x Gigabit LAN |
| CPU | ARM Cortex A17 (4 cores @Max. 1.4GHz) |
| RAM | 2G |
| Nand flash | 256M |
| Interface | 1x HDMI 2.0, Maximum support 3840 x2160@60fps |
| 1x VGA, Maximum support 2560 x1600@60fps | |
| 3x SATA | |
| 3x usb (1*3.0 + 2*2.0) | |
| System | LINUX |
| Package contents | TBS2660 |
| Power Adapter,AC Cable, HDMI Cable | |
