TBS6281SE DVB-T2/T/C TV Tuner PCIe Card

  • Product Model: TBS6281SE
  • text_weight 300.00g
  • Reward Points: 80
  • Price in reward points: 4000

In Stock

US$79.99

  • Qty.Range(unit) Price(per unit)
    2 + US$74.99
    6 + US$69.99

TBS6281SE is a dual tuner PCI-Express interface DVB-T2/T TV Tuner Card which supports watching or recording two different channels from two different frequencies simultaneously. TBS 6281 DVB-T2/T Dual Tuner Card can be used as a digital video recorder for recording digital terrestrial TV programs with full HDTV support. It also enables you to pause a live broadcast and continue from where you left with the Time-shifting function.


Main Features:

        Dual Channel Receiving simultaneously

        DVB-T2/T/C SD or HD TV receiving

        Low profile size

        High-definition video, real-time and scheduled video recording

        High sensitivity DVB-T2 dual tuner for the best digital TV reception

        Specifications:

        Support PLP( Physical Layer Pipe)

    DVB-T2/T2 Lite/T

        DVB-T2/T Receiving Channel: VHF band and UHF band

        Channel Bandwidth: 6, 7, 8 MHz

        DVB-T2/ T modulation type: QPSK, 16QAM, 64QAM, 256QAM

        FFT mode: 1K, 2K, 4K, 8K, 16K, 32K

        Code rate: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 7/8

        Guard interval: 1/4, 1/8, 1/16, 1/32, 1/64, 1/128, 19/128, 19/256

        Intermediate frequency:

        IF mode: Low IF

        Center IF Frequency: 3 ~ 5 MHz

        Note: default 4MHz

        RF-Input Impedance 75Ω (IEC-DIN female)

        RF-Output Impedance 75Ω (IEC-DIN male)

    DVB-C

        Fully compliant with DVB-C and ITU J83 A/B/C specifications

        Receiving Frequency: 47~862 MHz Tuning Range

        Input level: -65~-10dBm

        16QAM, 32QAM, 64QAM, 128QAM and 256QAM Support

        Symbol Rate: 0.87 to 9Mbaud


System Requirements

        Windows XP / Vista/ 7/8/10, Linux

        Available PCI Express x1, x4, x8 or x16 slot


Package contents:

        1 x TBS6281SE DVB-T2/T/C TV Tuner PCIe Card

        1 x Low profile bracket

        1x F connector
