TBS2610 1 HDMI + 2 AV/CVBS Video Encoder


TBS2610 1 HDMI + 2 AV/CVBS Video Encoder

  • Product Model:TBS2610
  • Weight:800.00g

In Stock

US$229.00

TBS2610 is a professiomal high-definition product which support 1 channel HD HDMI video and 2 channels CVBS/AV video input. 3 channels 3.5MM independent audio interface acquisition function. Dual Streams output H.264 format, Audio MP3/AAC format. The coding rate can be adjusted and the picture quality can be controlled. Support HTTP / RTSP / RTP/ TCP / RTMP / FLV/ UDP / ONVIF protocols.

Application:

  • Digital TV Broadcasting System
  • IPTV & OTT system
  • Digital Signage Project
  • Remote Video Conference
  • Live Streaming
  • Head-end system of Digital TV branch network

Specification:

Product model TBS2610 1*HDMI+2*AHD CVBS video encoder
Input 1 HDMI input, 2 channels CVBS input, 3 channels 3.5 audio input
Output 1 channel IP output
Video Input resolution 1920x1080/1680x1050/1280x720/1600x1200/960x540/720*576/704*576 And other conventional resolution
Coding standard H.264
Coding level H.264 BASELINE PROFILEH.264 MAIN PROFILEH.264 HIGH PROFILE
Encoded size 320*240~1920*1080(Can customize)
Video bit rate Rate control :CBR/VBR 16KBIT/S~12MBIT/S
Video frame rate 1080*60fps (5-60 Fps)
OSD Character ,images
Audio Input selection 1 channel embedded audio hdmi, 2 channel AV,1 channel 3.5MM independent audio(Support audio gain)
Audio coding AAC/MP3/G711
Audio bit rate 64Kb/s~384Kb/s
Sampling rate 32000、44100 48000etc
IPoutput 1 RJ 100M / 1000M adaptive Ethernet port, TS stream standard, dual-stream, ONVIF protocol
System Network protocol Supports HTTP, RTSP, RTMP, UDP, multicast, unicast
Configuration management Support IE configuration, remote upgrade
The common use Power supply 12V~2A
power consumption 5W
Size 100mm *118mm * 40mm(length*width*height)
Operating temperature -20℃+ 60℃
Working humidity < 90%, Non-condensing
Weight 0.3KG
