MOI-V IPTV Streaming Server Chassis (without DVB Tuner cards)


MOI-V IPTV Streaming Server Chassis (without DVB Tuner cards)

  • Model: MOI-V
  • Weight: 18,000.00g
  • Reward Points:2300

In Stock

US$2,300.00

MOI-V is TBS latest professional IPTV streaming server, with flexible x86 CPU (Upto Intel E5 Xeon) and Memory, it support up to 48 TV tuners of different DVB standard in 1U chassis. It can receive live TV signal using built-in TV tuners and stream the channels to your IPTV panel.

MOI-V is a customizable product, you could change CPU, RMA and SSD, and support to install 6 TBS TV tuner card inside, it's a ideal product for IPTV system integrators and TV service operators, allows you to use not only Linux and Ubuntu, but also Windows.

Key Features:

  • Live SD/HD TV streaming
  • Customizable configuration
  • Low power consumption
  • Supports up to 48 TV tuners (6 TV tuner PCIe cards) of different DVB standard


Specification:

Size 1U Chassis
Processor Xeon E3-1231 V3 (default)
Memory 4x 240-pin DDR3 DIMM sockets
Default Memory is 1x8G DDR3
Ethernet 2x Gigabit Ethernet LAN ports
1x RJ45 Dedicated IPMI LAN port
Serial ATA 2x SATA 3.0 (6Gb/s), 4x SATA 2.0(3Gb/s)
SSD 60G SSD
Serial Port/Header 2x COM ports (1 rear, 1 header)
FRONT PANEL Power on
Reset
Power LED
HDD LED
Display Interface 1x VGA D-Sub Connector
USB 2x USB 3.0 ports
6x USB 2.0 ports
PCI-E slot 6x PCIE1X/4x PCIE1X &1x PCIE4X
SBC dimension 9.6" x 9.6", (24.4cm x 24.4 cm)
Operating Systems Microsoft® Windows 8, Microsoft® Windows 7,
Microsoft® Windows® 7/8 embedded Standard, Microsoft® Windows® 7 Embedded Compact
Linux, Ubuntu,
DVB tuner card support Up to48 TV tuners (6 TV tuner PCIe cards)
Pre-installed software Tvheadend, VDR, MuMuDVB, DVBlast, szap-s2, dvbdate, dvbscan, dvbdstream, dvbsnoop, scan-s2, szap-s2, tzap-t2, LIRC, telnet, ssh, ftp, samba
