TBS6812/PT4K ISDB-T/S/S3 PCIe Card


TBS6812/PT4K ISDB-T/S/S3 PCIe Card

  • Product Model:TBS6812

In Stock

TBS6812/PT4K is the first "PC Tuner for 4K" developed by TBS technologies. TBS6812/PT4K works also as a digital video recorder for recording digital satellite/terrestrial TV programs with 4K/full-HD support. This ISDB-S & S3, ISDB-T TV tuner card is ready with windows BDA driver. It's ideal for recording not only full-HD but 4K channels on your desktop PC.

Benefits

  • ISDB-S & S3, ISDB-T dual tuner
  • Record 4K/full-HD TV programs on PC
  • Real-time signal quality monitoring
  • High reliability design, stable operation

Specifications

ISDB-S3:

  • Broadcasting Frequency range: 11.727~12.731GHz ( RHCP & LHCP transponders)
  • IF Frequency range: 1032~3224MHz
  • Signal Level: -80~-20dBm (nominal)
  • 9505/10678MHz LNB supported

ISDB-S:

  • Broadcasting Frequency range:11.727~12.731GHz ( RHCP transponders)
  • IF Frequency range: 1032~2072MHz
  • Signal Level: -80~-20dBm (nominal)
  • 10678MHz LNB supported

ISDB-T:

  • Frequency range: 90~770MHz
  • Signal Level: -80~-20dBm (nominal)
  • 6MHz transmission band supported
