Professional HD H.264/H.265 HDMI Video Encoder

  • Product Model: TBS2603
  • Weight: 760.00g
  • Reward Points: 240
  • Price in reward points: 12000

In Stock

US$199.00

TBS2603
HD H.264
H.265
HDMI VIDEO ENCODER


What's TBS2603 HD H.264/H.265 HDMI encoder?

TBS2603 professional H.265 HDMI encoder is our newest HD audio & video encoding device with powerful functionality. It supports 1 channel HDMI stream of H.264/H.265 encoding output and the AAC, Mp3 audio format. From any HDMI input source, it generates an H.264/H.265-encoded stream compliant with HTTP/RTSP/RTP/RTMP/UDP protocols and ONVIF. The product can be applied to education, health care, IPTV, conference, remote education, news interview, banking, transportation and other industries.

Application
  • IPTV
  • Digital Signage
  • Video Conference
  • Replace HD Video Capture Card
  • Hotel TV system
  • Live Broadcast
  • Teaching/Campus Broadcast
  • Recording System; NVR (Net Video Recorder)
Why you should choose H.265?

--Downsize large HD videos with nothing lost

An HD video is usually very large in size, so converting the HD video to an H.265 video is the perfect solution to save space while remain the video quality.

--Convert DVDs/Blu-rays to H.265 videos for feasible playback

If you want to view a DVD or Blu-ray movie on your video player devices, you need to convert the movie to a specific video at first. Here you can use H.265 encoder to get a video with high video quality and relatively smaller size.

--Convert regular videos to H.265 for better video quality

You can convert regular videos in other formats to H.265 videos with better video quality, and the file size is not large.


H.264 VS H.265

Table below gives a good basic idea of what sorts of benefits H.265 can offer compared to H.264.

H.265/HEVC H.264/AVC
Names MPEG-H, HEVC, Part 2 MPEG 4 Part 10, AVC
Approved date 2013 2003
Progression Successor to H.264/AVC Successor to MPEG-2 Part
Key improvement * 40-50% bit rate reduction compared with H.264 at the same visual quality
* It is likely to implement Ultra HD, 2K, 4K for Broadcast and Online (OTT)
* 40-50% bit rate reduction compared with MPEG-2 Part
* Available to deliver HD sources for Broadcast and Online
Support up to 8K

Yes No. Support up to 4K.
Support up to 300 fps Yes No. support up to 59.94 fps only.
How TBS2603 Works?
Product Features:

-- System supports WINDOWS XP/VISTA/SERVER2003/SERVER2008/WIN7 32 and WIN7 64; LINUX

-- Support multiple equipments display at the same time on a computer

-- Support direct network connection without HD capture card

-- Support RTSP/RTP/RTMP, HTTP, UDP protocol and ONVIF

-- Main stream and secondary stream can use different network protocols for transmission

-- Encoding specification: BASELINE PROFILE (for H.264 and H.265) / MAIN PROFILE (for H.264 only)/ HIGH PROFILE (for H.264 only)

-- CBR/VBR rate control, 16KBIT/S~12MBIT/S

-- Web control interface


Technical Specification

Video

Input 1x HDMI (1.3a)
HDMI Resolution 1920×1080_60i/60P, 1920×1080_50i, 1280×720_60p, 1280×720_50p and below
Encoding H.264/AVC Main Profile/High Profile ; H.265/HEVC Baseline
Profile; Audio AAC
Data Rate 0.8Mbps~12Mbps
Rate Control CBR/VBR
GOP Structure IBBP
Advanced Pretreatment De-interlacing, Noise Reduction, Sharpening

Audio

Encoding AAC, MP3
Sampling rate Auto
Bit-rate 48K/64K/96K/128K/160K/192K/256k
Sampling precision 16bit
Data Rate 64Kb/s ~ 384Kb/s

System

Ethernet/RJ45 1000 Base-T Ethernet interface
Protocol HTTP, UDP, RTP, RTSP, RTMP
Control Interface WEB
