TBS6903 Professional DVB-S2 Dual Tuner PCIe Card

  • Product Model: TBS6903
  • text_weight 350.00g
  • Reward Points: 230
  • Price in reward points: 11500

In Stock

US$229.99

  • Qty.Range(unit) Price(per unit)
    2 + US$224.99
    6 + US$219.99

TBS6903 is a Professional level digital satellite TV Tuner card with PCI Express interface. TBS6903 supports not only normal DVB-S2/DVB-S QPSK, 8PSK which is supported by normal satellite receivers, but also CCM, ACM, VCM, 16APSK, 32APSK, Multiple Transport Stream, Multiple Generic Stream, Combined Single Generic &Single TS, which most satellite receiving devices can’t support. With use of dedicated TBS tools, those special streams can be captured. The two advanced DVB-S2/S tuners enable you to watch TV channel from one satellite transponder, while recording channels from different satellite transponders from another tuner at the same time.


Main Features:

        DVB-S2/S dual tuner

        Watch & record satellite TV/ radio programs on PC

        CCM, VCM, ACM and Multi Input Stream support

        Generic stream mode Support

        Blind scan support

        EPG (Electronic Program Guide) support

        Unicable/one cable compatible

        High-speed data download via satellite


Applications:

        Data receiving

        IPTV streaming

        Media monitoring

        Digital content distribution


Specifications:

        Frequency range: 950~2150 MHz

        Dual channels DVB-S2/S 8PSK QPSK 16APSK 32APSK ACM/VCM

        Demodulator

        Symbol rate:

        Maximum symbol DVB-S2 rate limitations (Msymb/s)

Msymb/s
Demod
LDPC
Single
Dual
QPSK
67.5
13567.5
67.5
8PSK
67.5
9067.5
45
16APSK
67.5
67.5
67.5
33.7
32APSK
67.5
545427

        DVB-S QPSK +1/2,2/3,3/4,5/6,7/8

        Support Data Burst & Tone Burst

        Support DiSEqC2.X and Motor


System Requirements:

        Windows XP / Vista/ 7/8/10, Linux

        Available PCI Express x1, x4, x8 or x16 slot
