TBS6910SE DVB-S2X Dual Tuner Dual CI PCIe Card
TBS6910SE DVB-S2X Dual Tuner Dual CI PCIe Card
- Model: TBS6910SE
- Weight: 550.00g
Pre-Order
US$189.00
TBS6910SE DVB-S2X/S2 Dual Tuner Dual CI PCIe Card is a twin tuner digital satellite TV for watching or recording two different channels from two different frequencies simultaneously, it also supports VCM, which is considered as a professional TV tuner for industrial-level users.
You can use one tuner to watch TV channel while using another tuner to record/watch another channel from another transponder/ satellite at same time.
TBS6910SE is integrated with two CI slots, inserting the correct CAM and subscription smartcard into the CI slot makes it possible to watch encrypted pay TV.
Main Features
- Support dual DVB-S/S2/S2X
- Fast scanning functionality for all media
- Supports VCM and multi stream
- High-speed data download via satellite
- Watch & record satellite TV/ radio programs on PC
Applications
- Data receiving
- Media monitoring
- Digital content distribution
Specification
Model | TBS6910SE | |
Connection | PCI-express | |
2x RF in | ||
2x CI slot | ||
DVB-S/S2/S2X | ||
DVB-S/S2 | QPSK | 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 |
8PSK | 3/5, 2/3, 3/4, 5/6, 8/9, 9/10 | |
16APSK | 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 | |
32APSK | 3/4, 4/5, 5/6, 8/9, 9/10 | |
DVB-S2X | QPSK | 1/4,1/3, 2/5 (S2-MODCODs) |
1/2, 3/5, 2/3, 3/4, 4/5, 5/6 | ||
8/9, 9/10 (S2-MODCODs) | ||
11/45, 4/15, 14/45, 7/15 8/15, 32/45 | ||
8PSK (8APSK-L) | 3/5, 2/3, 3/4, 5/6, 8/9 (S2-MODCODs) | |
7/15, 8/15, 26/45, 32/45 | ||
16APSK | 2/3, 3/4, 4/5, 5/6, 8/9 (S2-MODCODs) | |
7/15, 8/15, 26/45, 3/5, 32/45 | ||
32APSK(32APSK-L) | 3/4 ,4/5,5/6, 8/9, 9/10 (S2-MODCODs)32/45, 11/15, 7/9,(2/3) | |
VCM | Yes | |
Symbol rate | 1 ~ 45Msymb/s | |
Power consumption | ||
Input/ Power: | 8 ~ 12W | |
temperature | 0° ~ 78° | |
System Requirements | Windows XP / Vista/ 7/8/10, Linux | |
Available PCI Express x1, x4, x8 or x16 slot | ||
Dimension: | ||
TV tuner card size | 104.5mm * 150mm | |
Gift Box Size | 200 * 130 * 30mm | |
Weight | 300g | |
Package Contents | 1 * TBS6910SE | |
1 * Power cable |
